Creating Custom Post Types Using Advanced Custom Fields

Introduction

For a long time the most popular way to create Custom Post Types (CPTs) was to use Custom Post Type UI (CPT-UI) to create the Custom Post Types and custom taxonomies and pair that with Advanced Custom Fields (ACF) for adding custom fields. However, ACF recently included the ability to create Custom Post Types and custom taxonomies without the need of another plugin and I predict this will quickly become the most used option.

In this tutorial I will do a walk-through using ACF free to create two Custom Post Types, with a relationship field joining them, create a custom taxonomy, and add custom fields.  I’ll also show you how to make the relationship field between the two Custom Post Types bi-directional.

Why ACF? There are several reasons why ACF it is often the chosen solution:

• Advanced Custom Fields has a free version with all of the basic field types. The free version has more than two million active installs. ACF Pro adds some additional field types and advanced features.
• ACF support is excellent and there are a large number of 3rd party extensions. There are tons of online tutorials and resources.
• ACF is the most widely supported tool. ACF fields are supported by all of the major page builders that have support for dynamic data (pulling data from the database).
• The professional versions of the major page builders have a “theme builder” option that allows you to create single and archive templates for your Custom Post Types. All of them support ACF.
• Now that some site builders are moving to Gutenberg and perhaps the Full Site Editor, you’ll find that ACF is also the most widely supported custom fields plugin there as well.

So now we know why ACF is the most popular choice, lets turn to the walk-through.

Video Walk-Through

Notes About Post Type Relationships

When you create post relationships there are some things to keep in mind:

• We have two Custom Post Types. The relationship field is the way to join them.
• Dividing the fields between two Custom Post Types help to avoid needing to enter the same data multiple times. In this case, for example, we have more than one book with the same author. It also makes the data easier to maintain as you only need to update it in one place.
• An ACF convenience is that you can visually pick the related record, but by default ACF relationships are one way.
• So, which Custom Post Type should have the relationship field, because that will be the one where you make the choice. Choosing implies that the other record already exists! So which Custom Post Type should get the relationship field?
• In this case, since there may be authors with more than one book, it makes sense to enter the authors first and then pick the author from the book edit screen second … so the relationship should go on the Audio Book Custom Post Type.

The trick to creating a bidirectional relationship is pretty easy:

1. Add a relationship field to both Custom Post Types.
2. Give them the same name.
3. Of course on the Audio Books relationship field you filter to show Book Authors and vis-a-versa.
4. Read about it in the ACF documentation and add the code snippet below.

Want to have a bidirectional relationship instead? The ACF documentation has a code snippet you can use.

function bidirectional_acf_update_value( $value, $post_id, $field  ) {

    // vars
    $field_name = $field['name'];
    $field_key = $field['key'];
    $global_name = 'is_updating_' . $field_name;


    // bail early if this filter was triggered from the update_field() function called within the loop below
    // - this prevents an inifinte loop
    if( !empty($GLOBALS[ $global_name ]) ) return $value;


    // set global variable to avoid inifite loop
    // - could also remove_filter() then add_filter() again, but this is simpler
    $GLOBALS[ $global_name ] = 1;


    // loop over selected posts and add this $post_id
    if( is_array($value) ) {

        foreach( $value as $post_id2 ) {

            // load existing related posts
            $value2 = get_field($field_name, $post_id2, false);


            // allow for selected posts to not contain a value
            if( empty($value2) ) {

                $value2 = array();

            }


            // bail early if the current $post_id is already found in selected post's $value2
            if( in_array($post_id, $value2) ) continue;


            // append the current $post_id to the selected post's 'related_posts' value
            $value2[] = $post_id;


            // update the selected post's value (use field's key for performance)
            update_field($field_key, $value2, $post_id2);

        }

    }


    // find posts which have been removed
    $old_value = get_field($field_name, $post_id, false);

    if( is_array($old_value) ) {

        foreach( $old_value as $post_id2 ) {

            // bail early if this value has not been removed
            if( is_array($value) && in_array($post_id2, $value) ) continue;


            // load existing related posts
            $value2 = get_field($field_name, $post_id2, false);


            // bail early if no value
            if( empty($value2) ) continue;


            // find the position of $post_id within $value2 so we can remove it
            $pos = array_search($post_id, $value2);


            // remove
            unset( $value2[ $pos] );


            // update the un-selected post's value (use field's key for performance)
            update_field($field_key, $value2, $post_id2);

        }

    }


    // reset global varibale to allow this filter to function as per normal
    $GLOBALS[ $global_name ] = 0;


    // return
    return $value;

}
add_filter('acf/update_value/book-author-relationship', 'bidirectional_acf_update_value', 10, 3);

Just be sure to change the last line to use the name of your relationship field.

Two facets of working with Custom Post Types

After you create the Custom Post Types, custom taxonomy, and add the custom fields, you are only half through. You also need to show the content on the front-end.

1. Creating them and adding the custom fields, entering the data in the admin.  Here we use tools like ACF, ACPT, CubeWP, JetEngine, Meta Box, Pods, or Toolset.
2. Creating single and archive templates to show them on the front-end.  Here we can create templates using PHP, in the Full Site Editor, or by using the theme builder functionality of pro page builders and Gutenberg solutions:  Beaver Builder / Beaver Themer, Breakdance, Bricks, Brizy, Builderius, Elementor, GeneratePress / Generate Blocks, JetThemeCore, Kadence Pro, Meta Box Views, Oxygen, Zion Builder and more.

There are a lot of tools available. I’ve looked at most of them. Have I missed the one you use? If so, please let me know.
